主要產品有YMQ系列商標模切機、SJQ系列切角機、SWY目錄索引挖月機、YP系列書芯壓平機、YYJ書背壓緊機及其它

PJQ-100型液壓切角機

本機適用于吊牌、鋁塑包裝袋、護卡膜、存折、筆記本、書籍等類似產品的圓角平角沖切。動力采用液壓裝置,設備裁切力量更大,可以切更大定制尺寸與異形尺寸產品。

PJQ-100型液壓切角機本機適用于吊牌、鋁塑包裝袋、護卡膜、存折、筆記本、書籍等類似產品的圓角平角沖切。動力采用液壓裝置,設備裁切力量更大,可以切更大定制尺寸與異形尺寸產品。

This machine is suitable for punching the round corner and flat angle of Hangtag, aluminum plastic packaging bag, protecting card film, Deposit Book, notebook, books and similar products. The power uses the hydraulic device, the equipment cuts the strength to be bigger, may cut the bigger custom size and the special size product.

Yqj-120 hydraulic angle cutting machine this machine is suitable for hanging tag, aluminum plastic packaging bag, card film, passbook, notebook, books and other similar products round corner flat angle punching. The power uses the hydraulic device, the equipment cuts the strength to be bigger, may cut the bigger custom size and the special size product.




型號

Model

PJQ-100(液壓型)

切角極大高度

Max. Cutting Height

120mm

切角速度

Cutting speed

80 Times/min

電機功率

Power

3HP / 2200W

工作電壓

Voltage

三相380V

整機重量

Weight of whole machine

300kg

外型尺寸

Overall dimensions

1260x620x1260 (mm)

臺面尺寸

Mesa dimension

550x580mm

刀具規格(選裝)

Tool Specifications(optional)

PJQ
R3/R4/R5R6/R7/R8/R9/R10/R12/R14/R16/R18/R20
/R22/R24/R27/R30/R35/R40
C42







<>
